■ Equipment Performance

Moduled steel frame structure to reduce the mechanical trouble effectively, Panasonic servo control system, imported straight track to support motion, imported metal sealed C02 radio-frequency tube,belt transmission, routeway feeding, coaxial infrared ray indicating position system, anodized aluminium lamella table, up&down worktable, air cooling, Error alarm system, exclusion of dust and smoke, inflatable protection, the proprietary software which support the output of various files format: PLT, BMP, DXF, Al, etc.

■ Applicable fields

Advertising industry, decoration, furniture, model manufacturing, and handicraft industry. The machine is widely applied in the fina engraving, cutting and hollowing out on nonme- tallic materials like acrylic, organic board, double color plate, plank, bamboo product, paper, glass, etc, With all kinds ofcharacters, graphs, images, trademarks and so on.

■ Optional configuration

Red-light locating system; Rotary device.

■ Main technical parameters

Type specification:   GGDK-1060/GGDK-1260/GGDK-1290

Laser power:   75W   100W

Connecting way:   PCI/USB  Online/offIine  reading U flash

Working platform size:   1000x600mm 1250x600mm 1250x900mm

Cutting speed:    ≤100 mm/s

Engraving speed:   ≤1000 mm/s

The accuracy of repeated orientataion:    ≤± 0.005mm

Cooling way:   Air cooIing/Circulation water cooling

Power supply:   220V/50Hz/lkVA

Net weight:   150kg/184kg/200kg

Dimension:   1240x1200x740  1520xl200x850/1580xl240x970mm
